SEBO Right-Hand Brush Roll ...
$10.00
Product details
Color is part of the part number on this one. Bearing block 5031DB1 is the dark blue version, entered by SEBO at position 122 of the AUTOMATIC X4 X5 parts diagram as the right hand bearing block in dark blue and gray black.
It fits the SEBO AUTOMATIC X4 and the SEBO AUTOMATIC X5. The block carries the right end of the brush roll and decides how freely it turns. A rasp on start-up, a roll that wanders sideways in its housing, or a belt that keeps walking off its track normally trace back to a worn block rather than to the roll itself. Hair and fine grit get past the seal, the bore opens up, and from then on the motor is working against drag that should not be there. Lift the roll out, swap the block, and look over the opposite end while everything is apart, since both sides have done the same hours.
The left-hand block is a separate number and depends on the machine: 5766HG on the AUTOMATIC X4, 5767HG on the AUTOMATIC X5. Belts 5110 and 5463 drive the roll, with motor pulley 5462 and pulley cover 5112SW behind them, and 5117/1 covering the sensor and motor pulleys together. Roll itself: 5010AM for the AUTOMATIC X4, brush roller set 5290AM for the AUTOMATIC X5. Dark blue trim parts that match this block are exhaust filter cover 5711DB, exhaust filter catch 5712DB and brush roller release 5713DB, with power head covers 5786AM for the AUTOMATIC X4 and 5796AM for the AUTOMATIC X5.
- Part number: 5031DB1
- Fits: SEBO AUTOMATIC X4 and SEBO AUTOMATIC X5
- Color: dark blue, listed by SEBO as dark blue and gray black
- Side: right hand
- Diagram position: 122, AUTOMATIC X4 X5 parts diagram
- Replace when: the roll rasps, wobbles by hand, or the belt will not stay centered
- Related part numbers: 5766HG and 5767HG left-hand blocks, 5110 and 5463 belts, 8366WS brush roller cleaning tool
Genuine SEBO stock through an authorized dealer, and the right answer for a SEBO brush roll bearing or AUTOMATIC X4 bearing block replacement in dark blue. Ships in 2-5 business days.
