SEBO Complete Front Bottom Plate for AUTOMATIC X2 and X5 — Gray Black

SEBO Complete Front Bottom Plate for AUTOMATIC X2 and X5 — Gray Black

View the SEBO AUTOMATIC X2 schematic and parts →View the SEBO AUTOMATIC X5 schematic and parts →
$12.00 USD
$12.00 USD
Sale Sold out
Shipping calculated at checkout.

5413GS
Authorized Sebo Dealer Factory warranty, extended free where we can
Free Shipping On Eligible Orders $100+
Secure Checkout SSL Encrypted

Shipping Information

We offer free standard shipping on eligible orders of $100 or more within the 48 contiguous United States. Eligibility is calculated on the merchandise subtotal after discounts and before tax.

Most in-stock orders using standard shipping are processed within 1-5 business days, and most arrive 2-11 business days after they are placed. Backordered and special-order items may take longer. Expedited UPS Ground is available at checkout for an extra charge, including on orders that qualify for free standard shipping. See our Shipping Policy for details.

Returns & Exchanges

Need to return an item? We’re happy to help. Eligible items may be returned by requesting authorization within 35 days of delivery. Once approved, your return must reach us within 21 days.

Return eligibility

Items must be unused, in new condition, and include their original packaging and all accessories. Machines that use water cannot be returned once unboxed, unless defective upon arrival.

Shipping and refunds

For non-defective returns, customers cover return shipping. Original shipping charges are nonrefundable. If your order included free shipping, our actual outbound shipping cost will be deducted from your refund. Eligible returns have no restocking fee.

Received a defective item?

Contact us so we can help arrange a prepaid return label and replacement.

Please review our Return & Refund Policy for complete details and exclusions.

Warranty Information

All products sold by Vacuums and More come with the manufacturer's warranty. Warranty terms vary by brand and product.

With 35 years of industry experience, we stand behind every product we sell. Contact us for warranty support.

View full details

SEBO Complete Front Bottom ...

$12.00

Product details

Item 134 on SEBO's AUTOMATIC X4/X5 parts sheet is the front bottom plate, and 5413GS is the gray black moulding sold complete for the AUTOMATIC X2 and the AUTOMATIC X5. It is the panel you see first when the cleaning head is tipped over: the leading strip of plastic running the full width of the sole, wrapping the front lip of the brush opening.

Everything about how the head meets the carpet passes through this piece. It sets the ride height at the front edge, holds the intake opening to the right shape, and gives the pile adjustment wheel at item 132 something square to work against when the height is dialled up or down. Surface scratching across the underside is normal and makes no difference to pickup. A crack, a broken mounting boss or a missing corner is another matter — the head then rocks instead of tracking flat, unmetered air enters through the split rather than through the brush opening, and the loose edge can score a hard floor.

Fitting one is a mechanical job once the head is turned over. The fasteners release, among them the M4 screw drawn at item 139, and the new moulding drops onto the same bosses. Look over the hinge at item 129 and the rear plate at item 135 while everything is exposed, since all three take their wear from the same carpet.

  • Order code: 5413GS
  • Machines covered: AUTOMATIC X2, AUTOMATIC X5
  • Moulded in: gray black
  • Comes as: one complete plate, ready to fit
  • Sheet reference: item 134, AUTOMATIC X4/X5 drawing
  • Around it on the sheet: hinge 5154GS at 129, pile adjustment wheel 5174GS at 132, rear plate 5414GS at 135, screw 0197 at 139

Anyone hunting a SEBO front bottom plate, an X2 sole plate or an AUTOMATIC X5 base plate replacement is looking at this number. Genuine SEBO part, shipped in 2-5 business days.
